3. Point to [Properties], and then click [Extended Features Settings].

4. Select the [Set Recovery/Parallel Printing for each port] check box.

5. Click [OK] to close the [Extended Features Settings] dialog box.

• For information about these settings, see SmartDeviceMonitor for Client Help.

1. Preparing for Printing
