2500-3500/ Translation of the original instructions

MAINTENANCE SUMMARY TABLE

PROCEDURE EVERY 8

HOURS

AFTER

20

HOURS

EVERY

50

Engine oil

check the level ●

change ● ●

Gearbox oil

Check the level ● ●

replace ●

Check that the engine intake grid is

clean

●

Check that tines are well-sharpened

and well-fixed

● ●

Lubricate with grease

If the machine is to be out of use for more than 30 days (models with petrol engine), drain the fuel from

the engine to prevent sticky deposits from forming in the fuel intake system or in vital parts of carburettor.

To avoid this procedure, it is possible to save fuel in storage up to 12 months by using an appropriate

fuel stabilizer. Add the such additive to the fuel in the tank or in the fuel container. Run the engine for a

while to let the stabilizer get into the fuel system. Important: if the engine is fed with petrol containing

alcohol, drain the fuel tank and run the engine until there is no fuel left.

TRANSPORTING THE MACHINE

If the tiller has to be transported on a lorry or a trailer, fasten it to the vehicle using ropes or cables.

IMPLEMENTS

CAUTION: Before fitting the tines assembly, ratchet hubs or wheel extensions to the tiller shaft (fig. 10),

ploughing without tiring the operator excessively. Two types of plough are available: single furrow and

turn-wrest at 180°. The latter is particularly advisable in jobs requiring work in both directions, such as

earthing-up along lines of vegetables, in vineyards or orchards. The depth of the furrow obtained may
