CL62/ Translation of the original instructions

HOURLY MOWING CAPACITY: 2000 m²/h.

DIMENSIONS: Length: 1969 mm – Width: 707 mm – Height: 1000 mm

WEIGHT: 90 kg

PUTTING THE MACHINE INTO SERVICE

1) Check that the machine has not been damaged during transport.

2) Check the oil levels of the engine and hydrostatic transmission.

3) Check the tyre pressure: 1,5 BAR rear wheels 4.00-8.

4) Turn the handlebar.

5) Install the front wheel support (fig.5).

6) Tighten the clamping and regulating screws of the front-wheel support firmly. The bearing inside the

support must block.

RUNNING IN – CAUTION!!

Change the engine oil after the first 5 working hours (SAE 30).

Check that there are no oil leaks or slack screws, especially those which fix the blade. After a couple of

working hours adjust the tension of the belt running from the engine to the cutting deck as well as the

blade brake tension(fig. 6 – fig. 7)

INSTRUCTIONS FOR USE

BEFORE STARTING THE ENGINE

Before starting the engine, always check that:

– the engine oil level is correct (fig. 8, ref. A) – (see the appropriate manual).

– the air grids for the engine cooling system are clean (fig. 10, ref. B).

– the air filter is thoroughly clean (fig. 10, ref. A) – (see the appropriate manual).

– the mowing deck is clean.

– the fins on the hydraulic motor are thoroughly clean (fig. 9, ref. A).

– the blades are well sharpened and secured to the blade holder.

Fill the fuel tank with fresh fuel using a funnel with a very fine filter (fig. 1, n°11).

STARTING THE ENGINE

– Push the throttle (fig.1, n°4).

– If the engine is cold, use the choke (fig.1, n°4). To start the engine, strongly pull the recoil starter (fig.

1, n°7).

– Wait a few minutes to allow the engine to warm up. Important: When travelling with the mower from

one place to another, engage the FORWARD/STOP lever only (fig. 1, n°1 – fig. 2).

STARTING WORK

– Choose the desired cutting height using the lever (fig. 1, n°10). Suitably accelerate the engine and

engage the PTO – CLUTCH lever (fig. 2, ref. B). Gently operate the forward lever (fig. 2, ref. C) and start

working. To stop the machine, release both levers on the handlebar (fig. 2, ref. D)

– The lever (fig. 2, ref. C) is used to select the working speed and to engage the reverse gear (fig. 2, ref.

C). Pushing the lever forward, the mower moves forward; pulling the lever backwards, the machine

moves in reverse – remember to always pull the lever gently. When both levers on the handlebar are

released, the lever goes automatically from the FORWARD position back to the STOP position.

- To insert the reverse gear (fig. 2, ref. C) the lever has to be kept pulled.

FRONT WHEEL BLOCK

When working on slopes, it is possible to block the front wheel lowering the plastic item (fig. 4, ref. A).
