20. Data Saving Operation

1. Under the voltage setting or current setting mode, push the STORE button to save the values of voltage

or currents into memory of power supply for future recall purpose.

2. Refer 3.3 or 3.4 for voltage or current setting mode.

3. Push STORE button to enter data saving mode, the minimum value position flashes and displays

STORE icon on LCD.

4. Move UP or DOWN arrow keys to select storage group serial number.

5. Click ENTER button to confirm data saving, click STORE button to exit data saving mode.

SET � STORE �� 1 ��2 ��ENTER -----> OK

21. Recall Saving Operation

Under the panel operating mode, push the RECALL button for retrieving the saved data from memory;

following the setting steps as below:

1. Switch on the power supply

2. Push RECALL button to enter data recall mode, the minimum value position is flashes and displays

RECALL icon on LCD.

3. Press UP or DOWN arrow keys to recall the stored group number, the default values from voltage or

current setting mode displayed in LCD.

4. Press ENTER button to confirm data recall, or press STORE button to exit data recall mode.

RECALL ��1 ��2 ��ENTER --------> OK

22. USB Power Charging

Push the USB button, the default setting is voltage @ 5.2V and current @ 2.5A, the LCD will display 5.2V,

with current value as 0A. Connect the mobile phone via USB cable for power charging or supply USB

power to any compatible device.

For battery charging, the USB ports are suitable for mobile phones. With automatic check func-
