AXIOMET AX-3004H [12/12] Current calibration

the LEFT or RIGHT arrow keys to move the cursors to left or right and push the UP or DOWN arrow keys

to adjust the values same as readings of external reference voltage meter, then click ENTER button to

finish the voltage bias calibration.

At the power supply displayed 2.000A & 30.00V in setting area of LCD, hold the LEFT or RIGHT

arrow keys to move the cursors to left or right and push the UP or DOWN arrow keys to adjust the values

same as readings of external reference voltage meter, then click ENTER button to finish the voltage gain

calibration.

25. Current Calibration

Push the V/A button and power supply displayed 0.500A & 30.00V in setting area of LCD and *.***A

displayed in the main part of LCD. Connect the output terminals with the external reference current

meter and the load (5Ω/100W), shift to CC mode. Hold the LEFT or RIGHT arrow keys to move

the cursors to left or right and push the UP or DOWN arrow keys to adjust the values same as read-

ings of the external reference current meter. Then click ENTER button to finish the current bias calibration.

While t the power supply displays 2.750A & 30.00V in the setting area of LCD, hold the LEFT or

RIGHT arrow keys to move the cursors to left or right and push the UP or DOWN arrow keys to adjust

the values same as readings of external reference voltage meter. Then click ENTER button to finish the

current gain calibration.

Push OUT button to exit and restart the power supply to complete the calibration function.
