AXIOMET AX-3004H [11/12] Calibration

tion, the supply will set the proper charging current automatically.

1. Push the OUT button to activate output mode.

2. Push the USB button and USB indicator will turn off to exit USB charging mode.

USB � OUT � OK

23. Calibration

Follow the below chart, connect the 5 digit displayed volt meter and current meter, please resistance

(10Ω/100W) into the output terminals. To calibrate, start from point of zero voltage – voltage

coefficient – and zero current – current coefficient.

Hold the SET button to switch on power supply until “REF” displayed in LCD to enter calibration

mode.

24. Voltage Calibration

At the power supply displayed 2.000A & 05.00V in setting area of LCD and **.**V displayed in main part

of LCD. Connect the output terminal with an external reference voltage meter and shift to CV mode. Hold
