Mipro ACT-707 [3/6] Act multi channel wireless receiver
![Mipro ACT-707 [3/6] Act multi channel wireless receiver](/views2/1665423/page3/bg3.png)
FrontPanel：
RearPanel：
(1)FrontAntennaAInputConnector:Allowsanoptionalrear-to-frontAntennakitforfrontantenna
placement.
(2)PowerSwitch&Indicator:Whenswitchisturnedon,redindicatorilluminatestodenotenormal
powerstatus.
(3)HeadphoneJack:Toconnecttoastereoheadphonetomonitoroutputsignals.
(4)HeadphoneVolumeControlandModuleSelector:Pushestheknobtoselectthemoduleyou
wouldliketomonitor;turnstheknobtoadjustthevolumeofthestereoheadphone.
(5)ModuleIndicator:Pointsoutselectedmonitoringmodule
(6)ReceiverModule1:FirstReceiverModuleSlot[Ch. 1]
(7)ReceiverModule2:SecondReceiverModuleSlot[Ch.2]
(8)ReceiverModule3:ThirdReceiverModuleSlot[Ch.3]
(9)ReceiverModule4:FourthReceiverModuleSlot[Ch.4]
(10)FrontAntennaBInputConnector: Allowsanoptionalrear-to-frontAntennakitforfrontantenna
placement.
2
2.PARTSNAMEANDFUNCTIONS
ACTMULTICHANNELWIRELESSRECEIVER
(11)RearAntennaBinputConnector:BAntennaconnectorcanbeinstalledwithantennadirectlyand
providespowerforantennabooster.
(12)HeatSink:Pleasekeepitadequatelyventilated.
(13)MixedAFOutputSocket:AbalancedoutputsocketformixedAFsignalsfromallinstalled
modules;2outputlevelstoswitchfrom.
(14)MixedAFOutputLevelSwitch:CanswitchtheoutputtoMICorAUXlevel.
(15)OutputSocketforModule4:Thebalancedoutputsocketforfourthreceivermodule.[Ch.4]
(16)OutputSocketforModule3:Thebalancedoutputsocketforthirdreceivermodule.[Ch.3]
(17)OutputSocketforModule2:Thebalancedoutputsocketforsecondreceivermodule.[Ch.2]
(18)OutputSocketforModule1:Thebalancedoutputsocketforfirstreceivermodule.[Ch.1]
(19)ComputerNetworkInterfaceConnector:Networksockettoconnecttothecomputerizedsystem-
monitoringprogram.
(20)RearAntennaAinputConnector:AAntennaconnectorcanbeinstalledwithantennadirectlyand
providespowerforantennabooster.
(21)DCInputSocket:Theinputsocketfor12VoltDCpower.Pleasenotethatthepolarityofthe
centralpininthesocketispositive(+).
(22)ACPowerSocket:TheinputsocketforACpower.UsesACpowerrangingfrom90ACVto264
ACVwithoutchanginganyapplication.
3
ACTMULTICHANNELWIRELESSRECEIVER
(Fig.1)
(Fig.2)
9 107 8
2 3
4 5
6
CH1 CH2 CH3
HEADPHONEPOWER
CH4CH3CH2CH1
PUSH
ACT-707
CH4
1
0
1
11 12 1413 1615 17 18 2019 21 22
