![Mipro ACT-707 [5/6] Act multi channel wireless receiver](/views2/1665423/page5/bg5.png)
7
Connectthenetworkinterfaceremoteconnector(19)onthebackofthereceivertothe
interfaceconverter(requiresatleast2linkingcablesforeachpairing).Then,useRS-232
cableconnectstheconvertertotheRS-232COMPORTonthecomputer.
RemovethedetachableconnectingbasefromtheREMOTEconnector(19),andpluginthe
leadingwires[Wire(-)andWire(+)].UsePhillips-typescrewdrivertorotatethescrewand
tightenthewires.(Showsinfigure9.)Oncecompleted,putthebasebacktothereceiverand
parallelconnectwithotherreceiversbeforefinallyconnectedtotheconverter.
(Fig.9)
5.COMPUTERNETWORKINTERFACEOPERATION
1.ExceptforACT-707MAreceivermodule,bothreceivermoduleswithLCDdisplay
[ACT-707MBandACT-707MC]havethemostadvancefunctionofcomputer-
network-interfacedcontrollingsystem.
2.WiringInstruction
ACTMULTICHANNELWIRELESSRECEIVER
6
1.Whenassemblythereceivermodulewiththereceiver,alignthereceivermodule
withtheinsertslotinthereceiverandpushingentlyfollowingbythebuilt-inguide
rail.Untilthereceivermodulecomestoafullystop,theinstallationofthereceiver
moduleiscompleted.(Illustratedbelow)
2.Whentakingthereceivermoduleapartfromthereceiver,haveaPhillips-type
screwdriveravailablefirst.Insertthescrewdriverintheindentationunderneaththe
frontalframeofthereceivermoduleandpushoutslightlytoreleasethemodule
fromthelockingmechanism.Oncethemoduleisfreefromlockingmechanism,
onecanretrievethemoduleeasily.
4.HOWTOASSEMBLYANDDISASSEMBLYARECEIVERMODULE
(Fig.8)
ACTMULTICHANNELWIRELESSRECEIVER
Pull
Pull
Align
Push
CONVERTER
TOPCRS-232COMPORT
TOPCKEYBOARDCONNECTOR
TOKEYBOARD CONNECTOR
Wire(-)
RX1
RX2
RX3
PC
Wire(+)
Wire(-)
Wire(+)
