Mipro ACT-707 [6/6] Act multi channel wireless receiver
![Mipro ACT-707 [6/6] Act multi channel wireless receiver](/views2/1665423/page6/bg6.png)
1.WhenusingDCpowersupply,pleasebeawareoftheoperatingvoltage.Firstof
all,pleasemakesureminimumof12voltscanbeobtainedforfunctionproperly.
However,thepowersupplyshouldnotexceeditsmaximumcapacityof15volts.
Whenthesupplyvoltageismorethan15volts,thesystemwillsuffersevere
internaldamage.Itispreferredthepowersourceisfromaregulatedpowerwith
theminimumcurrentof3A.
2.UseonlyMIPROstandardantennatoensurethesensitivityofthereceiver.
3.Useonlystereoinsteadofmonoheadphoneasthemonitoringheadphone.
4.Antennasockethas8-voltsDCpowersupply;pleasedonotshortthecircuitof
thispart.
9
6.CAUTIONS
ACTMULTICHANNELWIRELESSRECEIVER
8
③ Thisinterfacesystemadaptsparallelconnection.Therefore,ittakesonly2linkingwiresto
completetheconnectiontotheconverterofthewholesystem.
④
⑤
⑥
Thissystemcanconnectupto64receivermodulesforsimultaneousoperation.Hence,if4
receivermodulesareinstalledineachACT-707,thiscontrollingsystemcanoperateupto
16ACT-707receivers.
Thoughlongerthedistanceis,worsethestabilitywillbe;nevertheless,thenetwork
connectingcablecanstilloperatewhileitis3.However,itisour
recommendationtokeepthecableunder100meterslongtoensurehigh-speed
transmission.
PleaserefertotheLCDmodule'susersmanualforsoftwareoperation.
00meterslong
(Fig.10)
ACTMULTICHANNELWIRELESSRECEIVER
CONVERTER
TOPCRS-232COMPORT
Wire(-)
RX1
Wire(+)
RX2
RX3
