Mipro ACT-707 [4/6] Act multi channel wireless receiver
![Mipro ACT-707 [4/6] Act multi channel wireless receiver](/views2/1665423/page4/bg4.png)
1.Install2separateantennasontheantennasockets(11),(20)ontherearpanel.
Illustratedinfigure3.
2.Connectingthepowersupply:WhenusingACpowersupply,attachthefemaleend
ofthepowercordtothereceiver(22)andplugthemaleendtotheACpower
outlet.Afterward,taketheDCoutputcordfromthepowermoduleandpluginto
theDCinputsocket(21).Illustratedinfigure3.
3.ACT-707adaptsswitchingpowersupplymodule.Theswitchingpowersupplynot
onlycanbeusedwhileconnectedexternally(figure4),butalsostockinternallyin
thestoragecaseonthebackofthereceiver (figure3).
4.AudioOutputConnection
6.Toensurebestreceptionpossible,receivermustbeinstalledatleastonemeter
aboveground.Inaddition,thedistancebetweentransmitterandreceivermustbe
morethanonemeterandawayfromnoise.(Showsinfigure6)
7.Onthefrontpanelofthereceiver,4openingsarepre-drilledforinstantinstallation
onthestandard19-inchrackcase.(Showsinfigure7)
4 5
3:COLD
-
+
1:GND
2:HOT
3
21
ExternalPowerSupplyUnit
MixedOutput:Balancedoutputsocket(XLR)mustconnecttothebalancedinputsocketofthe
mixer.ThisoutputsocketgeneratesthemixedoutputofCh.1~Ch.4andtheoutput
sensitivitycanbeadjustedtoAUXlevelorMIClevelbythelevelswitchontherightsideof
thesocket.Generallyspeaking,AUXlevelistocoordinatetheinputsensitivityofelectricguitar
amplifier.
IndependentOutputs:Therearefourbalancedoutputsocketsforindividualoutputsof
CH1~CH4.Allusebalanced(XLR)outputsocketsandtheoutputsensitivitieshadbeenpre-
settomicleveltocoordinatetheinputlevelofthemixer(MIClevelaswell).(Figure5
5.AntennaSocket:Theantennasocketprovides8VoltDCpower,whichenableyou
topairwithMIPRO'santennaboosterdirectly.Whentheconnectingcableforthe
antennaismorethan10meter,itisrecommendedtoinstallantennaboosterto
makeupthesignallosscausedbythecableandtoensurethesensitivityof
reception.
InternalPowerSupplyAssembly
ACTMULTICHANNELWIRELESSRECEIVER
3.INSTALLATIONOFTHERECEIVER
(Fig.3)
(Fig.5) (Fig.6) (Fig.7)
(Fig.4)
ACTMULTICHANNELWIRELESSRECEIVER
CH3AFOUTPUT MIXED LEVEL
MIC AUX
2:HOT
3.COLD
1:GND
CH4 CH2 CH1
+8VDCOUT
ANTENNAB
REMOTE DCIN(12~15V)
