Инструкция по эксплуатации Страница: 4

Sanus VLF220-B1 Black [4/38] Required tools

(6901-002111 <01>)

M4 M6 / M8

002938.eps

LF220 - Parts list

M8 x 45mm

M6 x 40mm

M4 x 30mm

14mm

24mm

M4 x 12mm

M6 x 14mm

M8 x 16mm

[01] x 1

[02] x 1 [03] x 1

[04] x 4

[05] x 4

[06] x 4

[09] x 4[08] x 4

[07] x 4

[10] x 4

[13] x 1

[11] x 4

[14] x 4

[12] x 4

[15] x 4

10 mm

(3/8 in.)

5.5mm

(7/32 in.)

13 mm

(1/2 in.)

[16] x 4

[17] x 4

[18] x 4

[19] x 4

[20] x 4

[21] x 2

[22] x 2

[24] x 4

[23] x 4

5/16 x 3.5 in.

3/16 in.

5/32 in.

Supplied Parts and Hardware

WARNING: This product contains small items that could be a choking hazard if swallowed.

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged

item to your dealer; contact Customer Service. Never use damaged parts!

NOTE: M4, M6, or M8 describes the diameter, mm describes the length of screws that are labeled M0 X 00mm. Not all hardware included

will be used.

Required Tools
