- 105 -

Appendix

The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio quality.

1. Connecting a S/PDIF Out Cable:

Connect a S/PDIF optical cable to an external decoder for transmitting the S/PDIF digital audio signals.

Connects to a S/PDIF optical cable

6-1-2 ConguringS/PDIFOut

2. Configuring S/PDIF Out:

On the Realtek Digital Output screen, Select the sample

rate and bit depth in the Default Format section.

6-1-3 Using the Voice Recorder

A. Recording Audio

1. To begin the recording, click the Record icon .

2. To stop the recording, click the Stop recording icon .

B. Playing the Recorded Sound

The recordings will saved in Documents>Sound Recordings. Voice Recorder records audio in MPEG-4 (.m4a)

format. You can play the recording with a digital media player program that supports the audio file format.

After setting up the audio input device, to open the

Voice Recorder, go to the Start menu and search for

Voice Recorder.
