Box Contents

Z490 AORUS XTREME WF (Z490 AORUS XTREME WATERFORCE)

motherboard

One water cooling kit

OneAORUSUSBashdrivewithdrivers

User's Manual

Quick Installation Guide

Six SATA cables

Two antennas

Two addressable LED strip adapter cables

Two RGB LED strip extension cables

One front panel extension cable

One front USB header extension cable

One AORUS RGB Fan Commander

One ESSential USB DAC

One noise detection cable

Two thermistor cables

One G Connector

Two Velcro Cable Ties

Optional Items



2-port USB 2.0 bracket (Part No. 12CR1-1UB030-6*R)



eSATA bracket (Part No. 12CF1-3SATPW-4*R)



3.5" Front Panel with 2 USB 3.2 Gen 1 ports (Part No. 12CR1-FPX582-2*R)

The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.
