1507/1503
Users Manual
8
Table 4 Display Indicators (cont.)
Indicator Description
P d Polarization index or dielectric
absorption ratio test is selected
ZERO Ohms lead zero is active.
VAC, VDC, Ω,
kΩ, MΩ, GΩ
Measurement units
88.8.8 Primary display
V
DC
Volts
1888 Secondary display
COMPARE Indicates selected pass/fail compare
value.
t Insulation test indicator. Appears when
insulation test voltage is present.
Table 5. Error Messages
Message Description
batt
Appears on the primary display and
indicates that the battery is too low for
reliable operation. The Tester will not
operate at all until the battery is replaced.
The B also appears when batt is on the
primary display.
> Indicates an out of range value.
CAL Err Invalid calibration data. Calibrate the Tester.
