Insulation Testers

Specifications

IP Rating..............................................................IP40

Altitude ................................................................Operating: 2000 m CAT IV 600 V, 3000 m CAT III 600 V

Non Operating (Storage): 12,000 m

Over-Range Capability........................................110% of range

Compliance to EN 61557 ....................................IEC61557-1, IEC61557-2, IEC61557-4, IEC61557-10

Model 1503 Accessories .....................................TL224 Leads

TP74 Probes

Clips PN 1958654 (red) and PN 1958646 (black)

Holster

Model 1507 Accessories .....................................TL224 Leads

TP74 Probes

Clips PN 1958654 (red) and PN 1958646 (black)

Holster

Remote Probe

AC/DC Voltage Measurement

Accuracy

Range Resolution

50 Hz to 400 Hz

± (% of Rdg + Digits)

600.0 V 0.1 V + (2 % + 3)

Input Impedance..................................................3 MΩ (nominal), <100 pF

Common Mode Rejection Ratio

(1 kΩ unbalanced)...............................................>60 dB at dc, 50 or 60 Hz

Overload Protection.............................................600 V rms or dc
