Insulation Testers
Input Terminals
9
Input Terminals
Input terminals are shown in Figure 4 and described in
Table 6.
1 3
2
bbw08f.eps
Figure 4. Input Terminals
Table 6. Input Terminal Descriptions
.
Item Description
A
Input terminal for resistance measurement.
B Common (return) terminal for all measurements.
C Input terminal for volts or insulation test.
Power-Up Options
Holding a button down while turning the Tester on
activates a power-up option. Power-up options allow you
to use additional features and functions of the Tester. To
select a power-up option, hold down the appropriate
button indicated while turning the Tester from OFF to any
switch position. Power-up options are cancelled when the
Tester is turned OFF. Power-up options are described in
Table 7.
