Indesit WITXL 1251 [3/84] The first wash cycle

Connecting the drain hose

Connect the drain

hose, without bending

it, to a drainage duct

or a wall drain located

at a height between

65 and 100 cm from

the floor;

alternatively, rest it on

the side of a washba-

sin or bathtub, faste-

ning the duct sup-

plied to the tap (see

figure). The free end

of the hose should

not be underwater.

! We advise against the use of hose extensions;

if it is absolutely necessary, the extension must

have the same diameter as the original hose and

must not exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

• the socket is earthed and complies with all

applicable laws;

• the socket is able to withstand the maximum

power load of the appliance as indicated in the

Technical data table (see opposite);

• the power supply voltage falls within the va-

lues indicated in the Technical data table (see

opposite);

• the socket is compatible with the plug of the

washing machine. If this is not the case, repla-

ce the socket or the plug.

! The washing machine must not be installed

outdoors, even in covered areas. It is extremely

dangerous to leave the appliance exposed to

rain, storms and other weather conditions.

! When the washing machine has been installed,

the electricity socket must be within easy reach.

! Do not use extension cords or multiple sockets.

! The cable should not be bent or compressed.

! The power supply cable must only be replaced

by authorised technicians.

Warning! The company shall not be held respon-

sible in the event that these regulations are not

respected.

The first wash cycle

Once the appliance has been installed, and be-

fore you use it for the first time, run a wash cycle

with detergent and no laundry, setting the 90°C

programme without a pre-wash cycle.

65 - 100 cm

Technical details

Model

WITXL 1251

Dimensions

40 cm wide

85 cm high

60 cm deep

Capacity

from 1 to 6 kg

Electric

connections

Please refer to the technical

data plate fixed to the ma-

chine.

Water

connections

maximum pressure 1 MPa

(10 bar) minimum pressure

0.05 MPa (0.5 bar) drum

capacity 42 litres

Spin speed

up to 1200 rpm

Test wash

cycles in

accordan-

ce with

directives

1061/2010

and

1015/2010.

Programme

: Cotton stan-

dard 60°C;

Programme : Cotton stan-

dard 40°C.

This appliance is compliant

with the following European

Community Directives:

- 2004/108/CEE (Electroma-

gnetic Compatibility)

- 2006/95/CE (Low Voltage)

- 2012/19/EU
