MEAN WELL NMP1K2 [3/12] Series

650W/1200W Modular Power

NMP series

SPECIFICATION

Front-End

NMP650 (4 Slots) NMP1K2 (6 Slots)

MODEL

VOLTAGE RANGE

Note.6

FREQUENCY RANGE

POWER FACTOR

EFFICIENCY(Typ.)

Note.4

AC CURRENT

INPUT

INRUSH CURRENT

LEAKAGE CURRENT

90 ~ 264VAC 120 ~370VDC

47 ~ 63Hz

PF>0.95/230VAC PF>0.98/115VAC at full load

6.7A/230VAC 13.5A/115VAC

40A/230VAC 25A/115VAC

3.5A/230VAC 7.5A/115VAC

8.%8 5 , full case load with each type of module at nominal voltage

91%, full case load with H / K module at nominal 24V / 48V only

40A/230VAC 25A/115VAC

Earth leakage current <400uA / 264VAC, Touch current <100uA/264VAC

1200W max.

5V @ 2A; tolerance 10%; ripple: 50mVp-p(max.)±

REMOTE CONTROL

ALARM SIGNAL

AUXILIARY POWER(AUX)

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

FUNCTION

-30 ~ +70 (Derate at 50 , refer to "Derating Curve")℃℃

20 ~ 90% RH non-condensing

RC+/RC-: Short, Power ON RC+/RC-: Open, Power OFF

TTL signal output for over temperature alarm. Please refer to the Function Manual.

5V @ 1.5A ; tolerance 10%; ripple: 50mVp-p (max.)±

-40 ~ +85 , 10 ~ 95% RH non-condensing℃

±℃ ℃0.03%/ (0 ~ 50 )

10~500Hz, 2G 10min./1 cycle, 60 min. each along X, Y, Z axes.

ANSI/AAMI ES60601-1, Ed. 3.1,UL62368-1; TUV EN60601-1, Ed. 3.1, EN62368-1; IEC 60601-1, Ed. 3.1, IEC 62368-1,TUV

IEC60950-1; EAC TP TC 004 approved

ISOLATION LEVEL

WITHSTAND VOLTAGE

Primary-Secondary: 2x MOPP, Primary-Earth: 1x MOPP

I/P-O/P: 4KVAC I/P-FG: 2KVAC O/P-FG: 0.5KVAC

ENVIRONMENT

SAFETY &

OUTPUT

650W max.

Shut down o/p voltage, recovers automatically after temperature goes down

TOTAL OUTPUT POWER

PROTECTION

OVER TEMPERATURE

ISOLATION RESISTANCE

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC / 25 / 70% RH℃

EMC

(Note 5)

OTHERS

DIMENSION

PACKING

250*89*41mm (L*W*H) 250*127*41mm (L*W*H)

1.45Kg (typ.); 9pcs / 14Kg / 0.98CUFT 2Kg (typ.); 6pcs / 13Kg / 0.88CUFT

Parameter

ESD

RF field

EFT/ Burst

Surge

Conducted

Magnetic Field

Voltage Dips and Interruptions

Conducted

Radiated

Harmonic Current

Voltage Flicker

Standard

EN55032 (CISPR32) / EN55011 (CISPR11)

EN61000-3-2

EN61000-3-3

EN61000-4-2

EN61000-4-3

EN61000-4-4

EN61000-4-5

EN61000-4-6

EN61000-4-8

EN61000-4-11

Test Level / Note

Class B

Class A

-----

EMC IMMUNITY

EMC EMISSION

EN60601-1-2, EN55024

Level 4, 15KV air; Level 4, 8KV contact

Level 3, 10V/m

Level 3, 2KV

Level 4, 4KV/Line-FG; 2KV/Line-Line

Level 2, 3V

Level 4, 30A/m

100% dip 1 periods, 30% dip 25 periods,

100% interruptions 250 periods

File Name:NMP-SPEC 2018-09-18

9%0.5 , full case load with H / K module at nominal 24V / 48V only
