Derating Curve
Static Characteristics
LOAD (%)
LOAD (%)
INPUT VOLTAGE (VAC) 60Hz
90 110 130 150 264
90
100
80
70
60
50
40
AMBIENT TEMPERATURE ( )℃
20
40
50
60
80
100
-30010203040506070
(HORIZONTAL)
115VAC
230VAC
-25
230VAC ONLY
100
CONTUINUOUS
MECHANICAL SPECIFICATION
※ NMP1K2
※AC Input Terminal Pin No. Assignment
Pin No.
1
3
2
Assignment Diagram Mxa imum mounting torque
12Kgf-cm
AC/N
AC/L
※ Mounting Instruction
Hole No. Recommended Screw Size MAX. Penetration Depth L Recommended mounting torque
1
2
4mm
4mm
M4
M4
7~1 Kgf-cm0
7~1 Kgf-cm0
FG
650W/1200W Modular Power
NMP series
Case No.260 Unit:mm
Air flow
direction
CN32
6
5
2
1
TB1
1
2
3
14 max.
219.1
4-M4(Both Sides) L=4
250
10 max.
20.5
8.611
41
6.1
4-M4 L=4
92
122
+V
-V
9.5
8
23.5
80
127
14.8
20
20
20
20
20
12.2
2
1
1
1
1
2
File Name:NMP-SPEC 2018-09-18
Mounting Screw
Mounting Surface
Chassis of NMP
(thickness 1.6mm)
L
