MEAN WELL NMP1K2 [4/12] Series

OUTPUT

(NMS-240)

DC VOLTAGE

CONFIGURATION CODE

MODEL

NMS-240-05 NMS-240-12 NMS-240-24 NMS-240-48

12V

24V

48V

36A 20A 10A 5A

0 ~ 36A

0 ~ 20A 0 ~ 10A

0 ~ 5A

180W

100mVp-p

3 ~ 6V

240W

150mVp-p

6~15V

240W

150mVp-p

15~30V

240W

250mVp-p

30~55V

±2.0% ±1.0% ±1.0% ±1.0%

±0.5% ±0.3% ±0.2% ±0.2%

±1.0% ±0.5% ±0.5% ±0.5%

1500ms, 60ms at full load

16ms/230VAC @ 75% total output power 10ms/230VAC @ total output power

RATED CURRENT

CURRENT RANGE

RATED POWER

RIPPLE & NOISE (max.)

Note.2

VOLTAGE ADJ. RANGE

VOLTAGE TOLERANCE

Note.3

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

105 ~ 125% rated output power

OVERLOAD

OVER VOLTAGE

PROTECTION

Protection type : Shut down o/p voltage, re-power on to recover

Protection type: constant current limiting protection

6.1 ~ 8V 15.1 ~ 20V

6 ~ 15V

30.1 ~ 37V

15 ~ 30V

56 ~ 66V

30 ~ 55V

REMOTE ON/OFF CONTROL

REMOTE SENSE

OUTPUT VOLTAGE PROGRAMMABLE(PV)

OUTPUT CURRENT PROGRAMMABLE(PC)

AUXILIARY POWER(AUX)

CURRENT SHARING(CS)

DC OK SIGNAL

RC+/RC-: Open, Power ON RC+/RC-: Short, Power OFF

Compensate voltage drop on the load wiring up to 0.5V.

Adjustment of output voltage is allowable. Please refer to the Function Manual.

3 ~ 6V

Adjustment of constant current level is allowable. Please refer to the Function Manual.

5V@10mA; tolerance 10%, ripple: 50mVp-p (max.)±

Please refer to the Function Manual.

Output modules turn on=4.5 ~ 5.5V, turn off=0 ~ 0.5V. Please refer to the Function Manual.

FUNCTION

■ Output Module (240W)

650W/1200W Modular Power

NMP series

OTHERS

DIMENSION

PACKING

118.5*37.9*18mm (L*W*H)

0.142Kg (typ.); 72pcs / 11.2Kg / 1.04CUFT

File Name:NMP-SPEC 2018-09-18

NOTE

1. All parameters NOT specifically mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance: includes set up tolerance, line regulation and load regulation.

4. NMP650: The efficiency changes by installing different output modules. The following combination is chosen when fitting different types of module:

5V (Voltage code C)*1, 12V (Voltage code E)*1, 24V (Voltage code H)*1, 48V (Voltage code K)*1. (650W max.)

NMP1K2: The efficiency changes by installing different output modules. The following combination is chosen when fitting different types of module:

5V (Voltage code C)*1, 12V (Voltage code E)*1, 24V (Voltage code H)*2, 48V (Voltage code K)*2. (1200W max.)

The hold up time of the combination above is 16ms/230vac @ 75% total output power 10ms/230VAC @ total output power.、

5. have The power supply is considered a component which will be installed into a final equipment. All the EMC tests been executed by mounting the unit on

a mm* mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives.360 720 For guidance on how to

perform these EMC tests, please refer to EMI testing of component power supplies. (as available on http://www.meanwell.com)

6. De-rating may be needed under low input voltages. Please check the derating curve for more details.

7. Under parallel operation ripple of the output voltage may be higher than the SPEC at light load condition.

8. The ambient temperature derating of 3.5 /1000m with fanless models and of 5 /1000m with fan models for operating altitude higher than 2000m (6500ft).℃℃

Shut down o/p voltage, recovers automatically after temperature goes down

OVER TEMPERATURE
