Gigabyte MZ72-HB0 (rev. 1.x) [10/141] 2 product specifications
![Gigabyte MZ72-HB0 (rev. 1.x) [10/141] 2 product specifications](/views2/1679966/page10/bga.png)
Hardware Installation - 10 -
1-2 Product Specications
CPU AMD EPYC™ 7002 series processor family
Dual processors, 7nm, Socket SP3
Up to 64-core, 128 threads per processor
cTDP up to 280W
Chipset System on Chip
Memory 16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200/ 2933 MHz
Onboard
Graphics
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
LAN 2 x 10GbE LAN ports (1 x Broadcom® BCM57416B)
1 x 10/100/1000 management LAN
Expansion Slots Slot_6: 1 x PCIe x16 (Gen4 x16 bus) slot ( from CPU_0)
Slot_4: 1 x PCIe x16 (Gen4 x16 bus) slot ( from CPU_0)
Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot ( from CPU_1)
Slot_2: 1 x PCIe x16 (Gen4 x8 bus) slot ( from CPU_0)
Slot_1: 1 x PCIe x16 (Gen4 x8 bus) slot ( from CPU_1)
1 x M.2 slot:
- M-key
- PCIe Gen4 x4
- Supports NGFF-2280/22110 cards
2 x U.2 ports:
- SlimSAS 4i type
- PCIe Gen4 x4 per port
Storage Interface
4 x 7-pin SATA 6Gb/s ports
3 x SlimSAS (with 12 x SATA 6Gb/s or 3 x U.2 PCIe Gen4 x4) ports
