- 9 - Hardware Installation
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can
become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read
the user's manual and follow these procedures:
•
Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
•
Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
•
When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
•
When handling the motherboard, avoid touching any metal leads or connectors.
•
It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap,keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.
•
Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
•
Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
•
Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
•
Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
•
To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
•
Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
•
Do not place the computer system on an uneven surface
.
•
Do not place the computer system in a high-temperature environment.
•
Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
•
If you are uncertain about any installation steps or have a problem related to the use of the
product,pleaseconsultacertiedcomputertechnician.
Chapter 1 Hardware Installation
Содержание
- 2020 giga byte technology co ltd all rights reserved the trademarks mentioned in this manual are legally registered to their respective owners 2
- Copyright 2
- Disclaimer 2
- Documentation classifications 2
- For any general sales or marketing enquires you may message gigabyte server directly by email server grp gigabyte com 2
- For further technical assistance please contact your gigabyte representative or visit http esupport gigabyte com to create a new support ticket 2
- For gigabyte distributors and resellers additional sales marketing materials are available from our reseller portal http reseller b2b gigabyte com 2
- For more information 2
- Forrelatedproductspecifications thelatestfirmwareandsoftware andotherinformation pleasevisit our website at http www gigabyte com 2
- In order to assist in the use of this product gigabyte provides the following types of documentation 2
- Information in this manual is protected by copyright laws and is the property of gigabyte changes to the specifications and features in this manual may be made by gigabyte without prior notice no part of this manual may be reproduced copied translated transmitted or published in any form or by any means without gigabyte s prior written permission 2
- 1 installation precautions 9 3
- 1 the main menu 30 3
- 2 advanced menu 33 3
- 2 productspecifications 10 3
- 3 installing and removing the cpu and heat sink 12 3
- 4 installing and removing memory 13 3
- 5 installing and removing the m ssd module 16 3
- 6 back panel connectors 17 3
- 7 internal connectors 18 3
- 8 jumper settings 27 3
- Chapter 2 bios setup 8 3
- Mz72 hb0 motherboard layout block diagram chapter 1 hardware installation 3
- Table of contents 3
- 10 abl post codes 120 4
- 11 agesa post codes 130 4
- 3 amd cbs menu 68 4
- 4 amd pbs menu 103 4
- 5 chipset setup menu 106 4
- 6 server management menu 108 4
- 7 security menu 114 4
- 8 boot menu 117 4
- 9 save exit menu 119 4
- 12 bios post beep code ami standard 141 5
- 2 3 4 5 6 6
- Mz72 hb0 motherboard layout 6
- Block diagram 8
- 1 installation precautions 9
- Chapter 1 hardware installation 9
- 2 product specifications 10
- 3 installing and removing the cpu and heat sink 12
- Follow these instructions to install the cpu 12
- 13 hardware installation 13
- 4 1 8 channel memory configuration 13
- 4 installing and removing memory 13
- Always turn off the computer and unplug the power cord from the power outlet before installing 13
- Direction if you are unable to insert the memory switch the direction 13
- Memory modules have a foolproof design a memory module can be installed in only one 13
- Read the following guidelines before you begin to install the memory make sure that the motherboard supports the memory it is recommended that memory of the 13
- Same capacity brand speed and chips be used 13
- The memory to prevent hardware damage 13
- This motherboard provides 16 ddr4 memory sockets and supports 8 channel technology after the memory isinstalled thebioswillautomaticallydetectthespecificationsandcapacityofthememory 13
- 4 2 installing and removing a memory module 14
- 4 3 dimm population table 14
- Before installing a memory module make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module be sure to install ddr4 dimms on to this motherboard 14
- Close the plastic clip at both edges of the dimm slots to lock the dimm module 14
- Follow these instructions to install a dimm module 14
- Hardware installation 14 14
- Insert the dimm memory module vertically into the dimm slot and push it down 14
- Rdimm maximum frequency supported table 14
- Reverse the installation steps when you want to remove the dimm module 14
- 15 hardware installation 15
- Ds rdimm maximum frequency supported table 15
- Lrdimm maximum frequency supported table 15
- 5 installing and removing the m ssd module 16
- 100 1000 server management lan port 17
- 6 back panel connectors 17
- Gbase t rj 45 lan port 1 17
- Gbase t rj 45 lan port 2 17
- Id button with led 17
- Serial port 17
- Usb 3 ports 17
- Vga port 17
- 5 6 7 8 18
- 7 internal connectors 18
- 19 hardware installation 19
- 2 3 atx p12v_1 p12v_2 2x12 main power connector and 2x4 12v power connector 19
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 19
- With the use of the power connector the power supply can supply enough stable power to all the components onthemotherboard beforeconnectingthepowerconnector firstmakesurethepowersupplyisturnedoff and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 19
- 5 6 7 sata0 sata1 sata2 sata3 sata 6gb s connectors 20
- Hardware installation 20 20
- Sata_sgp sata sgpio connector 20
- Serial general purpose input output sgpio is a communication method used between a host bus adapter hba and a main board 20
- The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s standard each sata connector supports a single sata device 20
- 10 11 12 13 14 cpu0_fan cpu1_fan sys_fan1 sys_fan2 sys_fan3 sys_fan4 cpu fan system fan headers 21
- 21 hardware installation 21
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from 21
- Headers 21
- Overheating overheating may result in damage to the cpu or the system may hang 21
- Pmbus connector 21
- The motherboard has one 4 pin cpu fan header cpu_fan and two 4 pin sys_fan system fan headers most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the motherboard supports cpu fan speed control which requires the use of a cpu fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 21
- The power management bus pmbus is a variant of the system management bus smbus which is targeted at digital management of power supplies 21
- Thesefanheadersarenotconfigurationjumperblocks donotplaceajumpercaponthe 21
- 17 f_usb3 f_usb2 usb 3 connector 2 header 22
- Com2 serial port cable connector 22
- Hardware installation 22 22
- No pin 22
- Pinno definition 22
- The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 22
- Theconnector headerconformtousb2 3 specification eachusbconnector headercanprovidetwo usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 22
- 23 hardware installation 23
- Connect the power switch reset switch speaker chassis intrusion switch sensor and system status indicator on the chassis to this header according to the pin assignments below note the positive and negative pins before connecting the cables 23
- Fp_1 front panel header 23
- The front panel design may differ by chassis a front panel module mainly consists of power switch reset switch power led hard drive activity led speaker etc when connecting your chassis front panel module to this header make sure the wire assignments and the pin assignments are matched correctly 23
- Bp_1 hdd backplane board header 24
- Hardware installation 24 24
- Spi_tpm trusted platform module connector 24
- Trusted platform module tpm is an international standard for a secure cryptoprocessor a dedicated microcontroller designed to secure hardware through integrated cryptographic keys 24
- 25 hardware installation 25
- Ipmb intelligent platform management bus connector 25
- Led_bmc bmc firmware readiness led 25
- The intelligent platform management bus communications protocol defines a byte level transport for transferringintelligentplatformmanagementinterfacespecification ipmi messagesbetweenintelligenti2c devices 25
- Bat battery socket 26
- 8 jumper settings 27
- Bios setup program function keys 28
- Chapter 2 bios setup 28
- Advanced 29
- Amd cbs 29
- Amd pbs option 29
- Chipset 29
- Save exit 29
- Security 29
- Server management 29
- 1 the main menu 30
- 2 advanced menu 33
- 2 1 trusted computing 34
- 2 2 psp firmware versions 35
- 2 3 legacy video select 36
- 2 4 ast2500 super io configuration 37
- 2 4 1 serial port 1 2 configuration 38
- 2 5 s5 rtc wake settings 40
- 2 6 serial port console redirection 41
- 2 7 cpu configuration 45
- 2 8 ami graphic output protocol policy 46
- 2 9 pci subsystem settings 47
- 2 10 usb configuration 48
- 2 11 nvme configuration 50
- 2 12 sata configuration 51
- 2 13 uefi post logo configuration 52
- 2 14 t1s auth configuration 53
- 2 15 network stack configuration 54
- 2 16 amd mem configuration status 55
- 2 17 iscsi configuration 56
- 2 18 broadcom bcm57416 10gbase t network connection 57
- 2 18 1 iscsi boot configuration menu 60
- 2 19 vlan configuration 63
- 2 20 mac ipv4 network configuration 65
- 2 21 mac ipv6 network configuration 66
- 3 amd cbs menu 68
- 3 1 cpu common options 69
- 3 1 1 performance 71
- 3 1 2 prefetcher settings 72
- 3 1 3 core watchdog 73
- 3 2 df common options 74
- 3 2 1 scrubber 75
- 3 2 2 memory addressing 76
- 3 2 3 acpi 77
- 3 2 4 link 78
- 3 3 umc common options 79
- 3 3 1 ddr4 common options 80
- 3 3 1 1 dram controller configuration 81
- 3 3 1 2 cad bus configuration 82
- 3 3 1 3 data bus configuration 83
- 3 3 1 4 common ras 84
- 3 3 1 5 security 86
- 3 3 2 dram memory mapping 87
- 3 3 3 nvdimm 88
- 3 3 4 memory mbist 89
- 3 3 4 1 data eye 90
- 3 4 nbio common options 92
- 3 4 1 smu common options 94
- 3 4 2 nbio ras common options 96
- 3 5 fch common options 98
- 3 5 1 ac power loss options 99
- 3 5 2 fch ras options 100
- 3 6 ntb common options 101
- 3 7 soc miscellaneous control 102
- 4 amd pbs menu 103
- 4 1 ras 104
- 5 chipset setup menu 106
- 5 1 north bridge 107
- 6 server management menu 108
- 6 1 system event log 110
- 6 2 view fru information 111
- 6 3 bmc network configuration 112
- 6 4 ipv6 bmc network configuration 113
- 7 security menu 114
- 7 1 secure boot 115
- 8 boot menu 117
- 9 save exit menu 119
- 10 1 startprocessortestpoints 120
- 10 2 memory test points 120
- 10 3 pmu test points 120
- 10 abl post codes 120
- 10 4 original post code 121
- 10 5 cpu test points 122
- 10 6 topology test points 122
- 10 7 extended memory test point 122
- 10 8 gnb earlier init 123
- 10 10 abl0 test points 126
- 10 11 abl5 test points 126
- 10 9 pmu test points 126
- 11 1 universal post code 130
- 11 2 0xa1xx for cz only memory postcodes 130
- 11 agesa post codes 130
- 11 3 s3 interface post code 133
- 11 4 pmu post code 133
- 11 5 0xa5xx assigned for agesa psp module 133
- 11 6 0xa9xx 0xaaxx assigned for agesa nbio module 136
- 11 7 0xacxx assigned for agesa ccx module 138
- 11 8 0xadxx assigned for agesa df module 139
- 11 9 0xafxx assigned for agesa fch module 139
- 12 1 pei beep codes 141
- 12 2 dxe beep codes 141
- 12 bios post beep code ami standard 141
Похожие устройства
- Gigabyte MZ72-HB0 (rev. 1.x) Руководство пользователя GIGABYTE Management Console _AMI_
- Gigabyte MZ71-CE0 (rev. 1.x) Руководство пользователя ErP Mode BIOS Setup
- Gigabyte MZ71-CE0 (rev. 1.x) Руководство пользователя GIGABYTE GSM Agent
- Gigabyte MZ71-CE0 (rev. 1.x) Руководство пользователя GSM Server
- Gigabyte MZ71-CE0 (rev. 1.x) Инструкция
- Gigabyte MZ71-CE0 (rev. 1.x) Руководство пользователя GIGABYTE Management Console _AMI_
- Gigabyte MZ71-CE1 (rev. 1.x) Руководство пользователя ErP Mode BIOS Setup
- Gigabyte MZ71-CE1 (rev. 1.x) Руководство пользователя GIGABYTE GSM Agent
- Gigabyte MZ71-CE1 (rev. 1.x) Руководство пользователя GSM Server
- Gigabyte MZ71-CE1 (rev. 1.x) Руководство пользователя GIGABYTE Management Console _AMI_
- Gigabyte MZ71-CE1 (rev. 1.x) Инструкция
- Gigabyte MJ11-EC0 (rev. 1.2) Руководство пользователя GIGABYTE GSM Agent
- Gigabyte MJ11-EC0 (rev. 1.2) Руководство пользователя GSM Server
- Gigabyte MJ11-EC0 (rev. 1.2) Инструкция
- Gigabyte MJ11-EC0 (rev. 1.2) Руководство пользователя GIGABYTE Management Console _AMI_
- Gigabyte MH60-RE1 (rev. 1.1) Руководство пользователя Easy BIOS Refresh
- Gigabyte MH60-RE1 (rev. 1.1) Руководство пользователя Management Console
- Gigabyte MH60-RE1 (rev. 1.1) Руководство пользователя Server Management
- Gigabyte MZ31-AR0 (rev. 2.x) Руководство пользователя Easy BIOS Refresh
- Gigabyte MZ31-AR0 (rev. 2.x) Руководство пользователя Management Console
