Daikin EWADC13T-XRC2 [20/23] Service and limited warranty

D–EIMAC01502–18_02EN - 20/23

NOTE: Use of a water stream, such as a garden hose, against a surface loaded coil will drive the fibers and dirt into the

coil. This will make cleaning efforts more difficult. Surface loaded fibers must be completely removed prior to using low

velocity clean water rinse.

2. Rinse. Do not use any chemicals (including those advertised as coil cleaners) to wash microchannel heat exchangers.

NOTE: A monthly clean water rinse is recommended for coils that are applied in coastal or industrial environments to help

to remove chlorides, dirt and debris. It is very important when rinsing, to water temperature is less than 55 °C. An elevated

water temperature (not to exceed 55 °C) will reduce surface tension, increasing the ability to remove chlorides and dirt.

3. Quarterly cleaning is essential to extend the life of an E-coated coil and is required to maintain warranty coverage.

Failure to clean an E-coated coil will void the warranty and may result in reduced efficiency and durability in the

environment. For routine quarterly cleaning, first clean the coil with an approved coil cleaner. After cleaning the coils

with the approved cleaning agent, use the approved chloride remover to remove soluble salts and revitalize the unit.

NOTE: Harsh chemicals, household bleach or acid cleaners should not be used to clean E-coated coils. These cleaners

can be very difficult to rinse out of the coil and can accelerate corrosion and attack the E-coating. If there is dirt below the

9 SERVICE AND LIMITED WARRANTY

All units are factory-tested and guaranteed for 12 months as of the first start-up or 18 months as of delivery.

These units have been developed and constructed according to high quality standards ensuring years of failure-free

operation. It is important, however, to ensure proper and periodical maintenance in accordance with all the procedures

listed in this manual and with good practice of machines maintenance.

We strongly advise stipulating a maintenance contract with a service authorized by the manufacturer in order to ensure

efficient and problem-free service, thanks to the expertise and experience of our personnel.

It must also be taken into consideration that the unit requires maintenance also during the warranty period.

It must be borne in mind that operating the unit in an inappropriate manner, beyond its operating limits or not performing

proper maintenance according to this manual can void the warranty.

5. The water used for filling the water circuit must be clean and suitably treated. A mechanical filter must be installed at

the point closest to the evaporator inlet.

6. Unless there is a specific agreement at the time of ordering, the evaporator water flow rate must never be above 120%

and below 50% of the nominal flow rate.

10 PERIODIC OBLIGATORY CHECKS AND STARTING UP OF APPLIANCES UNDER PRESSURE

The units are included in category I → III of the classification established by the European Directive 2014/68/EU (PED).

For chillers belonging to this category, some local regulations require a periodic inspection by an authorized agency.

Please check with your local requirements.
