2.4 Expansion Slots (PCI Express Slots)
ere are 7 PCI Express slots on the motherboard.
PCIe slots:
PCIE1 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x8 lane width graphics cards.
PCIE3 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE4 (PCIe 3.0 x16 slot) is used for PCI Express x8 lane width graphics cards.
PCIE5 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE6 (PCIe 3.0 x16 slot) is used for PCI Express x8 lane width graphics cards.
PCIE7 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIe Slot Congurations
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5 PCIE6 PCIE7
Single Graphics Card N/A N/A N/A N/A N/A N/A x16
Two Graphics Cards
in
CrossFireX
TM
or SLI
TM
Mode
N/A N/A x16 N/A N/A N/A x16
ree Graphics
Cards in 3-Way
CrossFireX
TM
Mode
or 3-Way SLI
TM
Mode
N/A N/A x16 N/A x16 N/A x16
Four Graphics Cards
in
4-Way CrossFireX
TM
Mode
or 4-Way SLI
TM
Mode
x16 N/A x16 N/A x16 N/A x16
Before installing an expansion card, please make sure that the power supply is switched o
or the power cord is unplugged. Please read the documentation of the expansion card and
make necessary hardware settings for the card before you start the installation.
For a better thermal environment, please connect a chassis fan to the motherboard’s chas-
sis fan connector (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using multiple graphics
cards.
