15
1.5 ASRock Game Blaster (X79 Extreme6/GB)
ASRock Game Blaster is packed with the new earthshattering Creative Sound
Core3D quad-core sound and voice processor. It is designed to deliver sound and
voice with unbeatable quality and accurate 3D positional audio. It also boosts gam-
ing performance, enables dual LAN with teaming function, and allows users to
morph their voice into miscellaneous characters which is amusingly funny.
*** HDMI_SPDIF Header
** Front Panel Audio Header
* LAN RJ-45 Port
Coaxial SPDIF Out Port
Optical SPDIF Out Port
4 x 1/8” Mini Jacks
PCIE Gold Fingers
ASRock Game Blaster is a proprietary card instead of a standard PCI-E x1 card.
Thus, it is only supported by some of ASRock’s motherboards. Please refer to
ASRock’s website for the motherboard support list.
