72
2.25 Untied Overclocking Technology
This motherboard supports Untied Overclocking Technology, which means during
overclocking, BCLK enjoys better margin due to xed PCIE buses. Before you
enable Untied Overclocking function, please enter “Overclock Mode” option of UEFI
setup to set the selection from [Auto] to [Manual]. Therefore, BCLK is untied during
overclocking, but PCIE buses are in the xed mode so that BCLK can operate under
a more stable overclocking environment.
Please refer to the warning on page 9 for the possible overclocking risk
before you apply Untied Overclocking Technology.
14. Congure the team IP address.
a. From Control Panel, double-click Network Connections.
b. Right-click the name of the team to be congured, and then click Properties.
c. On the General tab, click Internet Protocol (TCP/IP), and then click
Properties.
d. Congure the IP address and any other necessary TCP/IP conguration for
the team, and then click OK when nished.
