ASRock X79 Extreme6/GB [57/101] Smart switches
![ASRock X79 Extreme6/GB [57/101] Smart switches](/views2/1686228/page57/bg39.png)
57
2.14 Smart Switches
The motherboard has three smart switches: power switch, reset switch and clear
CMOS switch, allowing users to quickly turn on/off or reset the sytem clear the
CMOS values.
Power Switch Power Switch is a smart switch,
(PWRBTN)
allowing users to quickly turn
(see p.12 No. 27)
on/off the system.
Reset Switch Reset Switch is a smart switch,
(RSTBTN)
allowing users to quickly reset
(see p.12 No. 26)
the system.
Clear CMOS Switch Clear CMOS Switch is a smart
(CLRCBTN)
switch, allowing users to quickly
(see p.13 No. 17)
clear the CMOS values.
