ASRock X58 SuperComputer [23/74] 23 23 23 23

2323

Step4. Connect a VGA cable or a DVI cable to the monitor connector or the DVI

connector of the graphics card that is inserted to PCIE1 slot.

Step3. Align and insert ASRock SLI_Bridge_3S Card to the goldfingers on each graphics

card. Make sure ASRock SLI_Bridge_3S Card is firmly in place.

ASRock SLI_Bridge_3S Card
