5757
5757
57
3.4.13.4.1
3.4.13.4.1
3.4.1
CPU ConfigurationCPU Configuration
CPU ConfigurationCPU Configuration
CPU Configuration
BIOS SETUP UTILITY
Configure advanced CPU settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select the ration
between CPU Core
Clock and the FSB
Frequency.
Intel (R) Xeon (R) CPU W 570 @ 3.20GHz
Frequency : 3.20GHz
Cache L1 : 128 KB
Cache L2 : 1024 KB
Cache L3 : 8192 KB
Ratio Status Unlocked (Min:12, Max:Unlimited)
Ratio Actual Value 24
Enhanced Halt State
Intel (R) Virtualization tech.
CPU Thermal Throttling
No-Excute Memory Protection
Hyper Threading Technology
Active Processor Cores
A20M
Intel (R) SpeedStep(tm) tech
Intel (R) TurboMode tech
[Disabled]
[Enabled]
[Enabled]
[Disabled]
[Enabled]
[Auto]
[Disabled]
[Auto]
[Enabled]
CPU Ratio
[Auto]
CPU Ratio
If the ratio status is unlocked, you will find this item appear to allow you
changing the ratio value of this motherboard.
Enhance Halt State
All processors support the Halt State (C1). The C1 state is supported
through the native processor instructions HLT and MWAIT and requires no
hardware support from the chipset. In the C1 power state, the processor
maintains the context of the system caches.
Intel (R) Virtualization tech.
When this option is set to [Enabled], a VMM (Virtual Machine Architecture)
can utilize the additional hardware capabilities provided by Vanderpool
Technology. This option will be hidden if the installed CPU does not support
Intel (R) Virtualization Technology.
CPU Thermal Throttling
You may select [Enabled] to enable CPU internal thermal control mechanism
to keep the CPU from overheated.
No-Excute Memory Protection
No-Execution (NX) Memory Protection Technology is an enhancement to the
IA-32 Intel Architecture. An IA-32 processor with “No Execute (NX) Memory
Protection” can prevent data pages from being used by malicious software to
execute code. This option will be hidden if the current CPU does not support
No-Excute Memory Protection.
