SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Platform - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
CPU - Intel
®
Socket 1366 Core
TM
i7 Processor Extreme Edition / Core
TM
i7 Processor Supports Intel
®
Dynamic Speed Technology
- System Bus up to 6400 MT/s; Intel
®
QuickPath Interconnect
- Supports Hyper-Threading Technology (see CAUTION 1)
- Supports Untied Overclocking Technology (see CAUTION 2)
- Supports EM64T CPU
Chipset - Northbridge: Intel
®
X58
- Southbridge: Intel
®
ICH10R
Memory - Triple Channel DDR3 Memory Technology (see CAUTION 3)
- 6 x DDR3 DIMM slots
- Supports DDR3 2000(OC)/1866(OC)/1600(OC)/1333(OC)/1066
non-ECC, un-buffered memory
- Supports DDR3 ECC, un-buffered memory with Intel
®
Workstation 1S Xeon
®
processors 3500 series
- Max. capacity of system memory: 24GB (see CAUTION 4)
- Supports Intel
®
Extreme Memory Profile (XMP)
Expansion Slot - 4 x PCI Express 2.0 x16 slots
(blue @ x8 / x16 mode, orange @ x8 / N/A mode)
(Double-wide slot spacing between each PCI-E slot)
- 3 x PCI slots
- Supports ATI
TM
CrossFireX
TM
, Quad CrossFireX
TM
- Supports NVIDIA
®
Quad SLI
TM
, 3-Way SLI
TM
and SLI
TM
- Supports NVIDIA
®
Tesla Personal Supercomputer with three
Tesla and one Quadro graphics cards
Audio - 7.1 CH Windows
®
Vista
TM
Premium Level HD Audio with
Content Protection
- DAC with 110dB dynamic range (ALC890 Audio Codec)
- DTS (Digital Theater Systems) support (see CAUTION 5)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
- Supports Dual LAN with Teaming function
Rear Panel I/O I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
