[CD/DVD]: This is used for IDE CD/DVD drives.

[ARMD]: This is used for IDE ARMD (ATAPI Removable Media Device),

such as MO.

Cylinders

This is used to configure the number of cylinders. Refer to the drive

documentation to determine the correct value.

Heads

This is used to configure the number of read/write heads. Refer to the

drive documentation to determine the correct values.

Write Pre-compensation

Enter Write Pre-compensation sector. Refer to the drive documentation to

determine the correct value.

Sectors

This is used to configure the number of sectors per track. Refer to the

drive documentation to determine the correct value.

Maximum Capacity

This field shows the drive’s maximum capacity as calculated by the BIOS

based on the drive information you entered.

LBA Mode

This allows user to select the LBA mode for a hard disk > 512 MB under

DOS and Windows; for Netware and UNIX user, select [Off] to disable the

LBA mode.

Block Mode

Set the block mode to [On] will enhance hard disk performance by reading

or writing more data during each transfer.

Fast Programmed I/O Modes

This allows user to set the PIO mode to enhance hard disk performance by

optimizing the hard disk timing.

32 Bit Transfer Mode

It allows user to enable 32-bit access to maximize the IDE hard disk data

transfer rate.

Ultra DMA Mode

Ultra DMA capability allows improved transfer speeds and data integrity

for compatible IDE devices. Set to [Disabled] to suppress Ultra DMA

capability.

3.3 Advanced, Security, Power, Boot, and Exit Menus

Detailed descriptions of these menus are listed in the Appendix. See page 23.
