1.3 Motherboard Layout
1 ATX power connector (ATXPWR1) 14 Infrared module connector (IR1)
2 CPU socket 15 Chassis speaker connector (SPEAKER1)
3 CPU fan connector (CPU_FAN1) 16 South Bridge controller
4 North Bridge controller 17 Clear CMOS (CLRCMOS1, 2-pin jumper)
5 184-pin DDR DIMM slots (DDR1, DDR2) 18 PCI slots (PCI 1- 5)
6 CPU heatsink retention module 19 Audio CODEC
7 Primary IDE connector (IDE1, Blue) 20 Front panel audio connector (AUDIO1)
8 Secondary IDE connector (IDE2, Black) 21 PCI LAN
9 Chassis fan connector (CHA_FAN1) 22 PS2_USB_PWR1 jumper
10 Floppy connector (FLOPPY1) 23 Internal audio connectors: AUX1 (White)
11 BIOS FWH chip 24 Internal audio connectors: CD1 (Black)
12 System panel connector (PANEL1) 25 AGP slot (1.5V_AGP1)
13 USB 2.0 header (USB45, Blue) 26 FSB select jumper (FSB)
27 Easy I/O header (EASY_IO1)
P4i45PE
`
PCI 5
PCI 4
PCI 3
PCI 2
PCI 1
PCI
LAN
Super
I/O
Audio CODEC
USB2.0
5.1CH
FSB800
USB45
1
IR1
1
SPEAKER1
1
FLOPPY1
2MB
BIOS
1.5V_AGP1
Intel
ICH4
CMOS
Battery
IDE1
IDE2
10
32
DDR DIMM1 (64/72 bit, 184-pin module)
DDR DIMM2 (64/72 bit, 184-pin module)
Intel
845PE
Chipset
mPGA478B
ATXPWR1
1
PS2_USB_PWR1
AUDIO1
1
HDLED RST
PLED PWRBTN
1
PANEL 1
CPU_FAN1
CLRCMOS1
CHA_FAN1
Mic
In
GAME AUDIO1
USB 2.0
Ports
LAN
Mic in
Line out
GAME AUDIO1
PARALLEL PORT
PS/2
Mouse
PS/2
Keyboard
COM1
Line
In
Line in
USB 2.0
Ports
CD1
AUX1
10
30.5cm (12.0 in)
8
7
9
16
17
11
14
12
15
5
21.8cm (8.6 in)
3
22
2
18
21
19
25
24
20
23
13
4
1
1
26
6
1
27
EASY_IO1
