1.2 Specifications
Platform: ATX form factor (12" x 8.6", 30.5 x 21.8 cm)
CPU: Socket 478 for Intel
®
Pentium
®
4/ Celeron
®
processor
Chipsets: North Bridge:
Intel
®
845PE chipsets, standard FSB 400 / 533MHz,
Max. 800+ MHz (overclocking, see CAUTION 1),
supports Hyper-Threading Technology (see CAUTION 2);
South Bridge:
Intel
®
ICH4
Clock Generator: 100 MHz - 248MHz
Memory: 2 DDR DIMM slots: DDR1 and DDR2 (PC2100 / PC2700), Max. 2GB
IDE: IDE1: ATA 100 / Ultra DMA Mode 5;
IDE2: ATA 100 / Ultra DMA Mode 5;
Can connect up to 4 IDE devices
Floppy Port: Supports 1 floppy disk drive
Audio: 5.1 channels AC’97 Audio
LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
Hardware Monitor: CPU temperature sensing (ASRock U-COP);
Chassis temperature sensing;
CPU overheat shutdown to protect CPU life (ASRock U-COP)
(see CAUTION 3);
Voltage monitoring: +12V, +5V, +3V, Vcore;
CPU fan tachometer; Chassis fan tachometer
PCI slots: 5 PCI slots with PCI Specification 2.2
AGP slot: 1 AGP slot, supports 1.5V, 4X AGP card (see CAUTION 4)
USB 2.0: 4 default USB 2.0 ports and one extra set of header for two
additional USB 2.0 ports upgrade (see CAUTION 5)
ASRock I/O
TM
: PS/2: 1 keyboard port / 1 mouse port;
1 RJ 45 port;
4 rear default USB 2.0 ports;
1 serial port: COM1; 1 parallel port: ECP/EPP support;
Audio Jack: Line Out/ Line In/ Microphone + 1 Game port
BIOS: AMI legal BIOS;Supports “Plug and Play”;
ACPI 1.1 compliance wake up events;
Supports jumperfree; SMBIOS 2.3.1 support;
CPU frequency stepless control
(only for advanced users’ reference, see CAUTION 6);
OS: Microsoft
®
Windows
®
98 SE / ME / 2000 / XP compliant
