ASRock IMB-1313 [6/46] Specifications
![ASRock IMB-1313 [6/46] Specifications](/views2/1693100/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Micro ATX (9.6-in x 9.6-in)
Processor
System
CPU
Intel
®
10
th
Gen (Cometlake-S) Core
TM
Processors, up to 125 W
Chipset
IMB1313: Intel
®
Q470E
IMB-X1313: Intel
®
W480E
Socket LGA1200
BIOS AMI SPI 256 Mbit
Memory
Technology
Dual Channel DDR4 2933/2666/2400 MHz
- Intel
®
Core
TM
i9/i7 CPUs support DDR4 up to
2933 MHz
- Intel
®
Core
TM
i5/i3 CPUs support DDR4 up to
2666 MHz
- Intel
®
Pentium
®
/Celeron
®
CPU support DDR4
up to 2400 MHz
Capacity
128GB*
* Intel
®
Core i9/i7/i5 CPUs support up to 128GB
(32GB per DIMM)
Intel
®
Core i3/Pentium
®
/Celeron
®
CPUs support
up to 64GB (16GB per DIMM)
Socket
4 x 288-pin Long-DIMM
Graphics
Controller Intel
®
UHD Graphics
HDMI
HDMI 2.0a
Max resolution up to 4096x2160 @60Hz
DisplayPort
DisplayPort 1.2, DP++
Max resolution up to 4096x2160@60Hz
VGA Max resolution up to 1920x1200@60Hz
LVDS Dual channel 24 bit up to 1920 x 1200@60Hz
eDP eDP 1.4 Max resolution up to 4096x2304@60Hz
DVI-D N/A
MultiDisplay Triple Display
Expansion
Slot
PCIe
2 x PCIe Gen3 Slots (PCIE1/PCIE2: single at
x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3))
(PCIE1: Support riser card x8/x8, x8/x4/x4)
2 x PCIe x4 (Gen3)
PCI N/A
Mini-PCIe N/A
