7
M.2
1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0
and CNVio for Wireless
1 x M.2 (Key B, 3042/3052) with PCIe x1/
USB 3.0/USB2.0 and SIMo for 4G/5G
SIM Socket 1 x SIM socket connected to M.2 key B
Audio
Interface
Realtek ALC897 HD, High Denition Audio.
Line-In/Line-Out/Mic-In
Ethernet
Controller/
Speed
LAN1: Intel
®
I225LM with 10/100/1000/2500
Mbps
LAN2: Intel
®
I219LM with 10/100/1000
Mbps, support AMT/vPro
Connector 2 x RJ-45
Rear I/O
HDMI 1 x HDMI 2.0a
DisplayPort 1 x DP1.2
VGA 1
DVI N/A
Ethernet 1 x 1 Gigabit LAN, 1 x 2.5 Gigabit LAN
USB 4 x USB 3.2 (Gen2), 2 x USB2.0
Audio 3 (Line-In, Line-Out, Mic-In)
COM 2 x COM (RS-232/422/485)
PS2 1
Internal
Connector
USB
4 x USB 3.2 Gen1 (2 x USB 3.2 Gen1
header)
2 x USB 2.0 (1 x 2.54 pitch header)
COM 4 x COM (RS-232)
Parallel 1 (shared with GPIO)
GPIO 8 x GPI, 8 x GPO (shared with LPT header)
TPM TPM 2.0 onboard
LVDS 1
eDP 1 (BOM Option support)
VGA N/A
SATA PWR
Output
N/A
Speaker
Header
1
