Storage
M.2
1 x M.2 (Key M, 2242/2260/2280) with
SATA and PCIe x4 f or SSD
* Shared with SATA3_5/SATA3_6 Ports
- When using M.2 PCIe x4 S SD, both
SATA3_5 and SATA_6 Ports are disabled
- When using M.2 SA TA SSD, only
SATA3_5 Port is disabled, and SATA3_6
Port is available
mSATA N/A
SATA 8 x SATA3 (6Gb/s)
eMMC N/A
Watchdog
Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR ATX PWR (24+8-pin)
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power
input ready
Environment
Operating
Temp
0ºC ~ 60ºC
Storage
Temp
-40°C ~ 85°C
Operating
Humidity
5% ~ 90%
Storage
Humidity
5% ~ 90%
