20
USB Power Setting Jumpers 1-2 : +5V
(3-pin USB2_PWR_0_1 (For USB2_0_1),
2-3 : +5VSB
USB2_PWR_2_3 (For USB2_2_3),
USB3_PWR1 (For USB3_12, USB3_34))
(see p.10, No. 30)
