1.2 Specications
IMB-194-D:
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1151 for Intel
®
Core i7/i5/i3/Celeron
(Skylake-S)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L2 Cache (By CPU)
Chipset Intel
®
Q170
BIOS UEFI
Expansion
Slot
Mini-PCIe
1 (half/full size, supports PCIe x1 and USB
device)
mSATA 1 (full size, shared with SATA and USB device)
PCIe 1 x PCIe x16 slot
Memory
Technology Dual Channel DDR4 2133MHz
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
Gen9 Graphics DX 11/12, OGL4.3/4.4
VRAM Shared Memory
VGA Supports Max resolution up to 1920 x 1200
LVDS 0
HDMI 1
DVI 0
DisplayPort
Supports Max resolution up to 4096 x 2160 @
60Hz
Multi Display Yes (Triple Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel
®
I219LM, 1 x Intel
®
I210
Connector 2 x RJ-45
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/s)
