USB 2.0 Headers There are two headers on this
(9-pin USB2_0_1, USB2_2_3:
motherboard. Each USB 2.0
see p.10, No. 31)
header can support two ports.
SATA3 Connectors These four Serial ATA3 (SATA3)
(SATA3_1~4: see p.10, No. 29)
connectors support SATA data
cables for internal storage
devices. The current SATA3
interface allows up to 6.0 Gb/s
data transfer rate.
SATA3_2
SATA3_1
SATA3_4
SATA3_3
Front Panel Audio Header This is an interface for front
(9-pin HD_AUDIO1)
panel audio cable that allows
(see p.10 No. 28)
convenient connection and
control of audio devices.
1. High Denition Audio supports Jack Sensing, but the panel wire on
the chassis must support HDA to function correctly. Please follow the
instruction in our manual and chassis manual to install your system.
2. If you use AC’97 audio panel, please install it to the front panel audio
header as below:
A. Connect Mic_IN (MIC) to MIC2_L.
B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_RET and OUT_RET are for HD audio panel only. You don’t
need to connect them for AC’97 audio panel.
E. To activate the front mic.
Go to the “FrontMic” Tab in the Realtek Control panel. Adjust
“Recording Volume”.
J _SENS
E
O UT2_L
1
M IC_RET
P RESENC E#
GND
O UT2_R
M IC2_R
M IC2_L
OUT_RET
LPC Header This connector supports a
(19-pin LPC1)
Trusted Platform Module (TPM)
(
see p.10, No. 20)
system, which can
securely store keys, digital
certicates, passwords, and
data. A TPM system also helps
enhance network security,
protects digital identities, and
ensures platform integrity.
1
GN D
GN D
S_ PWRDWN#
LA D2
SM B_CLK_M AIN
PC ICLK
PC IRST#
LA D3
+3 V
LA D0
GN D
FR AME
SM B_DATA_ MAIN
LA D1
SE RIRQ#
GN D
+3 VSB
48 MHz
+5 V
