ASRock 4X4-R1000V [25/32] Usb configuration
![ASRock 4X4-R1000V [25/32] Usb configuration](/views2/1693693/page25/bg19.png)
25
3.3.6 USB Conguration
Legacy USB Support
Use this option to select legacy support for USB devices. There are two
conguration options: [Enabled] and [UEFI Setup Only]. The default value
is [Enabled]. Please refer to below descriptions for the details of these two
options:
[Enabled] - Enables support for legacy USB.
[UEFI Setup Only] - USB devices are allowed to use only under UEFI
setup and Windows / Linux OS.
