ASRock 4X4-R1000V [6/32] Specifications
![ASRock 4X4-R1000V [6/32] Specifications](/views2/1693693/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions NUC 4.09" x 4.02" (104 x 102mm)
Processor
System
CPU
AMD Ryzen™ Embedded R-Series
(R1606G, DC, 2.6GHz, 12-25W) (4X4-R1000M)
(R1505G, DC, 2.4GHz, 12-25W) (4X4-R1000V)
AMD Ryzen™ Embedded V-Series
(V1605B, QC, 2GHz, 12-25W) (4X4-V1000M)
AMD Ryzen™ Embedded R-Series
(R1305G, DC, 2.5GHz, 8-10W) (4X4-R1000E)
Chipset SoC
Expansion
Slot
M.2
1 x Key M (2242/2260/2280 by BRACKET) with
PCIe x4 and SATA3 for SSD
1 x Key E (2230) with PCIe x1 and USB 2.0 for
Wireless
Memory
Technology Dual Channel DDR4 2400MHz
Max. 32GB
Socket 2 x SO-DIMM
ECC
Support
Yes
Graphics
Controller
AMD Radeon™ Vega 3 Graphics (4X4-R1000M /
4X4-R1000V)
AMD Radeon™ Vega 8 Graphics (4X4-V1000M)
HDMI
Supports HDMI 2.0, max resolution up to
4096x2160@ 60Hz
DisplayPort
DisplayPort 1.2a with max resolution up to 3840 x
2160@ 60Hz
Multi Display Triple Display
Ethernet
Ethernet 10/100/1000 Mbps
Controller 2 x Realtek RTL8111G
Front I/O
Front USB 1 x USB 3.1
Front Audio 1 (Mic-in, Line-out)
Rear I/O
HDMI 1
DisplayPort 2
Ethernet 2
USB 2 x USB 3.1
