Chapter 1: Introduction
Thank you for purchasing ASRockind
4X4-4800U / 4X4-4500U / 4X4-4300U
moth-
erboard, a reliable motherboard produced under ASRockind’s consistently stringent
quality control. It delivers excellent performance with robust design conforming to
ASRockind’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration
guide to BIOS setup and information of the Support CD.
Because the motherboard specications and the BIOS software might be
updated, the content of this manual will be subject to change without no-
tice. In case any modications of this manual occur, the updated version
will be available on ASRockind website without further notice. You may
nd the latest CPU support lists on ASRockind website as well.
ASRockind website https://www.asrockind.com/
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
https://www.asrockind.com/support/index.asp
1.1 Package Contents
ASRockind
4X4-4800U / 4X4-4500U / 4X4-4300U
Motherboard
(NUC 4.09” x 4.02” (104 x 102mm))
ASRockind
4X4-4800U / 4X4-4500U / 4X4-4300U
Driver CD
ASRockind
4X4-4800U / 4X4-4500U / 4X4-4300U
Jumper setting instruction
