7
Internal
Connector
USB 2 x USB2.0 (1 x 2.54 pitch header)
COM 1 x COM (RS-232/422/485)
TPM Innion SLB9670VQ2.0
eDP 1
Storage
M.2
1 x M.2 (KEY M, 2242/2260/2280) with
PCIe x4 and SATA3 for SSD
*M.2 Key M 2280 (Supported by bracket)
SATA 1 x SATA3.0 (6.0 Gb/s)
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 segments, 0,1,2…255sec
Power
Requirements
Input PWR 12V~19V DC-In Jack
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
Environment ATX: Press Button to PWR on
after Power input ready
Environment
Operating
Temp
0ºC ~ 60ºC
Storage
Temp
-40ºC ~ 85°C
Operating
Humidity
5% ~ 90%
Storage
Humidity
5% ~ 90%
