6
1.2 Specications
Form
Factor
Dimensions 4.09" x 4.02" (104 x 102mm)
Processor
System
CPU
Intel
®
Quad Core Braswell N3710 (With FAN)
Supports Hyper-Threading Technology
Core
Number
4
Max Speed (By CPU)
L2 Cache 2MB
Chipset N/A
BIOS UEFI
Expansion
Slot
Mini-PCIe 1 (half size, supports PCIe x1 & USB)
mSATA 1 (Only supports SATA)
Memory
Technology Dual Channel DDR3L 1066 / 1600 MHz SDRAM
Max. 16GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
Gen8 Intel
®
Graphics DX 11, OGL3.2
VRAM Shared Memory
VGA N/A
DVI N/A
LVDS N/A
HDMI
Supports HDMI 1.4a, max resolution up to 3840
x 2160@30Hz
DisplayPort
Supports DP 1.1a, max resolution up to
3840x2160@30Hz
Multi Display Yes (Triple Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller GbE LAN: 1x Realtek RTL 8111G
Connector 1 x RJ-45
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/S)
