8
1.3 Motherboard Layout
mini-PCIe
LAN1
AUDIO1
HDMI1
USB3_2
DC_IN1
mini-SATA
USB 3.0
T: USB4
B: USB3
HDMI_DP_1
HDMI2
PANEL1
HDLED RESET
PLED PWRB TN
1
USB3_TC_1
SATA3 _1
1
LPC1
IR1
DDR3_A1 (Support DDR3L Only)
DDR3_B1 (Support DDR3L Only)
SATA_ PW R1
1
CLRM OS1
1
2
3
4
5
N3710-NUC IPC
1 : Clear CMOS Pad (CLRMOS1)
2 :
System Panel Header (PANEL1)
3 :
SATA Power Output Connector (SATA_PWR1)
4 :
SATA3 Connector (SATA3_1)
5 : LPC Debug Header (LPC1)
