7
Rear I/O
VGA 0
DVI 0
HDMI 1
DisplayPort 0
Ethernet 1
USB 1 x USB 3.0 compatible with USB 2.0
Audio 2 (Mic-in, Line-out)
Serial 0
PS/2 0
Internal
Connector
USB 2 x USB 2.0 (1 x 2.00 pitch header)
LVDS/
Inverter
1/1
eDP 0
VGA 0
Serial
2 x COM (COM1 supports RS-232/422/485,
COM2 supports RS232 only)
SATA 1
mPCIe 1 (combo with mSATA)
Parallel 0
mSATA 1 (combo with mPCIe)
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR 12V DC-in
Power On
AT/ATX Supported
AT: Directly PWR on as power input ready
ATX: Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
