6
1.2 Specications
Form
Factor
Dimensions PICO-ITX (3.9-in x 2.8-in)
Processor
System
CPU BGA1296 for Intel
®
Apollo Lake SoC
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L2 Cache (By CPU)
Chipset (By CPU)
BIOS
UEFI
Expansion
Slot
MIOe
HDMI or DP, 1 x USB3.0, 1 x USB2.0, 3 x PCIe
x1, Line out, LPC bus, SMBus
Mini-PCIe
1 (combo with mSATA, full size, Mini PCIe mode
supports PCIe x1 and USB device)
mSATA
1 (combo with Mini PCIe, full size, mSATA mode
supports SATA and USB device)
M.2
1 x M.2 Slot (Key E), supports type 2230 for
WiFi + BT Module
Memory
Technology DDR3L 1333/1600/1867 MHz
Max. 8GB
Socket 1 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics 505
VRAM Shared Memory
VGA No
DVI No
LVDS
Supports max resolution up to
1920x1200@60Hz
HDMI
Supports max resolution up to
4096x2160@30Hz
DisplayPort No
Multi Display Yes (Dual Display, LVDS + HDMI)
Ethernet
Interface 10/100/1000 Mbps
Controller 1 x Intel
®
I210IT
Connector 1 x RJ45
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/s)
