ASRock NUC BOX 6100 [12/39] How to remove the bottom case
![ASRock NUC BOX 6100 [12/39] How to remove the bottom case](/views2/1693779/page12/bgc.png)
NUC BOX 6100
PB 7
English
Chapter 3 Hardware Installation
is chapter helps you install or remove important components.
3.1 How to Remove the Bottom Case
1. Remove the four screws on the bottom case.
2. en li up and remove the bottom panel..
2
1
