NUC BOX 6100
3 4
English
Chapter 2 Product Overview
is chapter provides diagrams showing the location of important components of
the NUC BOX 6100.
2.1 Front View
No. Description
1 Headphone & Microphone
2 USB 3.0 (Type A)
3 USB 3.1 (Type C)
4 IR Sensor Window
1 2 3
