ASRock NUC BOX 3000 (Barebone) [10/39] Rear view
![ASRock NUC BOX 3000 (Barebone) [10/39] Rear view](/views2/1693780/page10/bga.png)
5 6
English
2.2 Rear View
No. Description
1 DC-In
2 HDMI
3 RJ-45
4 Kensington Lock Slot
5 USB 3.0 (Type A)
6 *DisplayPort
*is DisplayPort only supports DP to D-Sub dongle and does not support DP to
HDMI dongle and DP to DVI dongle.
* ere are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
1 2 33 2 4
56
